Caltech India is the manufacturer and supplier of CES 547 Handheld Haze Meter. The CES 547 Haze Meter is a high precision handheld haze meter developed by us, designed to quickly and accurately measure the haze value and transmittance of transparent or semi-transparent materials. The instrument can easily achieve ASTM D1003, full transmittance, and haze testing. It is widely used in industries such as glass processing, plastic processing, film and display screen processing, packaging, liquid pharmaceutical analysis, etc. It is designed for plastic sheets, films, glasses, LCD panels, touch screen, and other transparent and semi-transparent materials haze and transmittance measurement. Contact us for the Haze Meter at Best Price.
Product Features:
1. The open measurement area supports both vertical and horizontal measurements, adapting to a wider range of measured samples, greatly improving the convenience and flexibility of measurement.
2. Only 100% calibration is required, which is quick and convenient for measurement work.
3. The instrument has high accuracy, a resolution of 0.1, good stability, repeatability < 0.1, and inter station difference 0.5.
4. The instrument is designed based on ergonomics, with a compact and beautiful appearance. The handshake position is equipped with an anti slip silicone pad, making it easy to grip. It is not only suitable for precision measurement in laboratories, but also convenient for flexible application in production sites.
5. The tilted 3.5-inch large screen is more ergonomic and can maintain comfort during daily or continuous work, effectively avoiding fatigue. During measurement, the screen can automatically rotate according to the instrument’s posture, providing users with an excellent operating experience.
6. Single measurement and average measurement modes can be freely switched to meet the measurement needs of different users.
7. Adopting high sensitivity, high speed, and low noise PD array detectors to meet the requirements of CIE V(λ) 2 degree visual response, achieving high-precision and repeatable measurement of transmittance and haze.
8. Using a 400-700nm full spectrum combination LED lighting source, it meets the measurement of haze and transmittance under three standard lighting sources: CIE-D65, CIE-A, and CIE-C.
9. Provide powerful haze and transmittance measurement and analysis software, suitable for quality monitoring and tabular management of haze and transmittance data in various industries. Generate test reports based on user test results to facilitate customer customization and management work.
Application Industry: The CES 547 haze meter is widely used in glass processing, plastic processing, film processing, display screen processing, packaging industry, liquid pharmaceutical analysis, and other fields.
Standards: ASTM D1003/1044, GB/T2410, JJF 1303-2011, CIE 15.2, JIS K7105, JIS K7361, JIS K 7136
Ordering Information:
| CES 547 - Handheld Haze Meter | |
| Product model | CES 547 |
| Lighting method | Transmission : 0/D (parallel light illumination, diffuse reflection reception); |
| Compliant with standards | ASTM D1003/1044, GB/T2410, JJF 1303-2011, CIE 15.2, JIS K7105, JIS K7361, JIS K 7136 |
| Features | The instrument can easily achieve ASTM D1003, full transmittance, and haze testing. Open measurement area for vertical and horizontal testing. It is widely used in industries such as glass processing, plastic processing, film, display screen processing, and packaging for transmittance and haze detection. |
| Integral Sphere Size | ⌀ 90mm |
| Lighting Source | 400-700nm combined LED light source |
| Splitting Method | / |
| Sensor | PD array detector, meeting CIE V(A) 2 degree visual response |
| Measurement Wavelength Range | / |
| Wavelength Interval | / |
| Half Bandwidth | / |
| Transmittance Measurement Range | 0-100% |
| Measurement Caliber | ⌀ 20mm |
| Sample Size | Thickness less than 40mm |
| Color Space | / |
| Color Difference Formula | / |
| Other Chromaticity Indicators | Haze (ASTM D1003/1044), Transmittance T (ASTM) |
| Observer Angle | 2° |
| Observation Light Source | D65, A, C |
| Display | Qualified/Unqualified Results |
| Measurement Time | approximately 1.5 seconds |
| Resolution | 0.1 units |
| Repeatability | 0.1 (⌀ 20mm caliber, after preheating and calibration of the instrument, test the standard haze film with a haze of about 30 at intervals of 5 seconds for 30 standard deviations) |
| Inter Station Difference | 0.5 (⌀ 20mm caliber, after instrument preheating correction, test the standard deviation between the haze standard haze sheet and the reference value at intervals of 5 seconds) |
| Dimensions | 100x129x238mm (LxWxH) |
| Weight | approximately 1.3kg |
| Power Supply Method | Built in 5000mAh lithium battery |
| Lighting Source Lifespan | 5 years, greater than 3 million measurements |
| Display Screen | TFT true color 3.5inch, capacitive touch screen |
| Interface | USB |
| Storage Data | 1000 standard samples and 10000 samples |
| Language | English |
| Operating Temperature Range | 0-40°C (32-104 ° F) |
| Storage Temperature Range | -20-50 °C (-4-122 ° F) |
| Standard Attachments | Power Adapter, Manual, Quality Management Software (Downloaded From Official Website), Data Cable, Measurement Caliber |
| Optional Accessories | Micro Printer, Testing Fixture, Standard Haze Film |
